Random Orbital Toolholders

Toolholders

PushCorp has designed a series of tool shafts to aid the customer when performing random orbital sanding operations. These are designed with counter weights and eccentrics based on the desired sanding disk diameter and orbit diameter. The 5" & 6" disc units are are tapped to accept 5/16-24 male threaded disks, while the 3" disc units are tapped for 1/4-20. Disks are available from several abrasive manufacturers to support a wide variety of media. The following charts show the appropriate PushCorp Assembly number for a desired Sanding Disk Diameter & Orbit Diameter.

ISO20 Options

Orbit Diameter	3"-3½" Disk	5" Disk	6" Disk
3/8"	ASM03980	ASM03983	ASM03986
3/16"	ASM03981	ASM03984	ASM03987
3/32"	ASM03982	ASM03985	ASM03988

Request a Quote

SM Options

Orbit Diameter	3″-3½” Disk	5″ Disk	6″ Disk
3/8″	ASM03367	ASM03364	ASM03361
3/16″	ASM03368	ASM03365	ASM03362
3/32″	ASM03369	ASM03366	ASM03363

BT30 Options

Orbit Diameter	3″-3½” Disk	5″ Disk	6″ Disk
3/8″	ASM02761	ASM02767	ASM02809
3/16″	ASM02762	ASM02765	ASM02768
3/32″	ASM02763	ASM02766	ASM02769

Product Downloads

3D & 2D Downloads

ISO20
	ASM03980 - 3.5 X 3/8 ORBIT SANDER 1/4-20 ISO20	Download
	ASM03981 - 3.5 X 3/16 ORBIT SANDER 1/4-20 ISO20	Download
	ASM03982 - 3.5 X 3/32 ORBIT SANDER 1/4-20 ISO20	Download
	ASM03983 - 5 X 3/8 ORBIT SANDER 5/16-24 ISO20	Download
	ASM03984 - 5 X 3/16 ORBIT SANDER 5/16-24 ISO20	Download
	ASM03985 - 5 X 3/32 ORBIT SANDER 5/16-24 ISO20	Download
	ASM03986 - 6 X 3/8 ORBIT SANDER 5/16-24 ISO20	Download
	ASM03987 - 6 X 3/16 ORBIT SANDER 5/16-24 ISO20	Download
	ASM03988 - 6 X 3/32 ORBIT SANDER 5/16-24 ISO20	Download

SM
	ASM03361 - SM 6IN-3/8IN ORBIT SANDER	Download
	ASM03362 - SM 6IN-3/16IN ORBIT SANDER	Download
	ASM03363 - SM 6IN-3/32IN ORBIT SANDER	Download
	ASM03364 - SM 5IN-3/8IN ORBIT SANDER	Download
	ASM03365 - SM 5IN-3/16IN ORBIT SANDER	Download
	ASM03366 - SM 5IN-3/32IN ORBIT SANDER	Download
	ASM03367 - SM 3.5IN-3/8IN ORBIT SANDER	Download
	ASM03368 - SM 3.5IN-3/16IN ORBIT SANDER	Download
	ASM03369 - SM 3.5IN-3/32IN ORBIT SANDER	Download

BT30
	ASM02761 - 3.5 X 3/8 ORBIT SANDER 1/4-20 BT30	Download
	ASM02762 - 3.5 X 3/16 ORBIT SANDER 1/4-20 BT30	Download
	ASM02763 - 3.5 X 3/32 ORBIT SANDER 1/4-20 BT30	Download
	ASM02767 - 5 X 3/8IN ORBIT SANDER 5/16-24 BT30	Download
	ASM02765 - 5 X 3/16IN ORBIT SANDER 5/16-24 BT30	Download
	ASM02766 - 5 X 3/32IN ORBIT SANDER 5/16-24 BT30	Download
	ASM02809 - 6IN-3/8IN ORBIT SANDER 5/16-24 BT30	Download
	ASM02768 - 6IN-3/16IN ORBIT SANDER 5/16-24 BT30	Download
	ASM02769 - 6IN-3/32IN ORBIT SANDER 5/16-24 BT30	Download
	ASM03532 - 1 IN X 4-1/2 IN MANDREL BT30 3.5IN-3/8IN ORBIT SANDER ADAPTER KIT	Download
	ASM03533 - 1 IN X 4-1/2 IN MANDREL BT30 3.5IN-3/16IN ORBIT SANDER ADAPTER KIT	Download
	ASM03550-1 - 4IN-3/8IN ORBIT DA DIAMOND WHEEL SANDER 1/2-13 BT30	Download

Accessories
	3.5IN Generic Back Up Pad - Thickness Not to Scale (Not for Sale)	Download
	5IN Generic Back Up Pad - Thickness Not to Scale (Not for Sale)	Download
	6IN Generic Back Up Pad - Thickness Not to Scale (Not for Sale)	Download

Common Pairings

Frequently used components and accessories with the Random Orbital Toolholders.

STC1202

STC1202 Series High-Speed, Robotic Servo Spindle The PushCorp STC1202...

Explore STC1202

SM1202

SM1202 Series High-Speed, Robotic Servo Spindle The PushCorp SM1202 high-speed...

Explore SM1202

STC1503-BT30

STC1503-BT30 High-Speed, Robotic Servo Spindle The PushCorp STC1503-BT30 high-speed servo...

Explore STC1503-BT30

SM1503

SM1503 High-Speed, Robotic Servo Spindle The PushCorp SM1503 high-speed servo spindle...

Explore SM1503

Ready to Automate?

Contact PushCorp today to integrate the Random Orbital Toolholders into your robotic system.

Request a Quote
